SMC VT307V-5G1-01
Electromagnetic Valves SS316
Product Description:
The VT307 Series is an updated range of direct-acting solenoid
valves by SMC. They provide many advantages compared with existing
models, such as low power consumption. In addition, they have two
other versions, namely vacuum and energy-saving. Moreover, voltage
surge suppression is also available.
For further details and technical specifications, head to the SMC
website. There you can learn more about the VT307 Series and how it
can help improve the performance of your system.
Features:
This 3-Port Solenoid Valve is a single valve, designed with various
functions. The rubber seal material is HNBR, which is very
resistant to low concentrations of ozone. It is direct operated
poppet type, designed for continuous-duty use. Not to mention, it
has an energy-saving type and a vacuum specification type available
as well. Furthermore, its mounting dimensions are interchangeable
with existing product, even more convenient for you.
Applications:
This product is suitable for a wide range of applications,
including:
- Blow-off valves
- Pressure release valves
- Single acting cylinder drives
- Divider valves
- Double acting cylinder drives
Technical Parameters:
| Standard Specifications |
| Type of actuation | Direct operated type 2 position single solenoid |
| Fluid | Air |
| Operating pressure range | 0 to 1 MPa (High-pressure type), 0 to 0.7 MPa (Standard type) |
| Ambient and fluid temperature | –10 to 50°C (No freezing) |
| Response time Note 1) | 20 ms or less (at 0.5 MPa) |
| Max. operating frequency | 10 Hz |
| Lubrication | Not required (Use turbine oil Class 1 ISO VG32, if lubricated.) |
| Manual override | Non-locking push type |
| Mounting orientation | Unrestricted |
| Impact/Vibration resistance Note 2) | 150/50 m/s^{2} |
| Enclosure | Dustproof |
Support and Services:
SMC Solenoid Valves Technical Support and Service
SMC provides their customers with technical support and service for
their solenoid valves. Our technical staff are knowledgeable in all
aspects of solenoid valve design and operation, and can help you
identify the right valve for your application. We also provide
installation and maintenance assistance to ensure your valve is up
and running as quickly as possible. Our comprehensive support also
includes troubleshooting services in the event that something goes
wrong.
We are committed to providing our customers with the highest
quality service and support. Our experienced staff are available to
answer any questions you may have and to provide you with the best
solutions for your solenoid valve needs. If you have any issues or
concerns, please do not hesitate to contact us.
Packing and Shipping:
SMC Solenoid Valves are packaged and shipped in accordance with the
following standards:
- Each unit is placed in a sealed, shock-resistant, protective
container.
- The boxes are labeled with the product's name, specifications, and
quantity.
- The boxes are securely packed in cardboard outer packaging with
sufficient cushioning material to prevent damage during transit.
- The shipment is tracked and insured to ensure on-time, safe
delivery.
FAQ:
Q1: What is the brand of the SMC Solenoid Valves?
A1: The brand of the SMC Solenoid Valves is SMC.
Q2: What is the model number of the SMC Solenoid Valves?
A2: The model number of the SMC Solenoid Valves is VT307V-5G1-01.
Q3: Where is the SMC Solenoid Valves made?
A3: The SMC Solenoid Valves is made in China.
Q4: Does the SMC Solenoid Valves have a certification?
A4: Yes, the SMC Solenoid Valves has a CE certification.
Q5: What is the minimum order quantity for the SMC Solenoid Valves?
A5: The minimum order quantity for the SMC Solenoid Valves is 1.
