FESTO LOE-1/8-D-MINI Zinc Alloy Oil Mist Eliminator,0.5-12 Bar
Product Description:
The air source treatment triple component refers to the triple
component composed of a pressure regulator, an oil filter, and a
lubricator, which plays an important role in pneumatic systems.
The air pressure regulator can adjust the pressure of the gas as
needed to ensure stable working pressure of the system and prevent
system failures caused by high or low pressure.
The oil filter can filter impurities and oil stains in the gas,
ensuring the cleanliness of the gas source and preventing pneumatic
components or systems from being contaminated and causing
malfunctions.
The lubricator can provide necessary lubricating oil for the
pneumatic system, reduce the friction loss of pneumatic components,
extend the service life of the system, and ensure the normal
operation of the system.
Therefore, the air source treatment triad can not only ensure the
normal operation of the pneumatic system, but also improve the
reliability and stability of the system, reduce faults and losses
caused by air source problems
Technical Parameters:
General technical data
Size | Mini | Midi | Maxi |
| Pneumatic connection 1, 2 | G1/8 | G1/4 | G1/4 | G3/8 | G1/2 | G1/2 | G3/4 |
| Type of mounting | With accessories |
| In-line installation |
| Mounting position | Vertical ±5° |
| Grade of filtration [μm] | 40 |
| Air purity class at the output | Compressed air to ISO 8573-1:2010 [7:4:–] |
| Inert gases |
| Bowl guard | Metal bowl guard |
| Condensate drain | Manual |
| Fully automatic |
| Actuator lock | Rotary knob with latch |
| Pressure regulation range [bar] | 0.5 ... 12 (0.05 ... 1.2 MPa) |
| Max. pressure hysteresis [bar] | 0.15
(0.015 MPa) | 0.2
(0.02 MPa) | 0.25 (0.025 MPa) | 0.2
(0.02 MPa) | 0.3
(0.03 MPa) | 0.1
(0.01 MPa) | 0.2
(0.02 MPa) |
| Pressure indicator | With pressure gauge |
| Max. condensate volume [cm^{3} ] | 22 | 43 | 80 (43)^1) |
Support and Services:
Technical Support and Service for Pneumatic Filter Regulator
Lubricator
We provide technical support and service for Pneumatic Filter
Regulator Lubricator, including:
- Installation and commissioning service.
- Maintenance and repair service.
- 24/7 online and phone support.
- Trouble-shooting service.
- Regular maintenance reminders.
Packing and Shipping:
Packaging and Shipping: Pneumatic Filter Regulator Lubricator
The Pneumatic Filter Regulator Lubricator (FRL) will be securely
packaged and shipped to ensure that it arrives in perfect
condition. All FRL units will be individually bubble-wrapped and
placed in a cardboard box with custom foam inserts which are
designed to fit the unit perfectly. This will protect the unit from
any damage during transit.
The cardboard boxes will be labeled with the FRL model number and
will also contain a packing slip with the customer’s contact
information and a list of the contents.
The FRL units will be shipped via a reputable courier and will
typically require a signature on delivery.
FAQ:
Q: What is the brand name of this product?
A: The brand name of this product is Festo.Q: What is the model number of this product?
A: The model number of this product is LOE-1/8-D-MIN.Q: Where is the place of origin of this product?
A: The place of origin of this product is China.Q: What is the minimum order quantity of this product?
A: The minimum order quantity of this product is 1.Q: What is the supply ability of this product?
A: The supply ability of this product is 5000PCs per month.
