LR-3/8-D-MINI-MPA FESTO Pressure Regulating Valve 1.6MPa

Ask Lasest Price
Brand Name :	Festo
Model Number :	LR-3/8-D-MINI-MPA
Certification :	CE
Price :	Negotiation
Payment Terms :	T/T, Western Union,Paypal
Supply Ability :	5000PCs per month
Delivery Time :	1-7Work Days After Payment

Add to Cart

Product Details
Company Profile

LR-3/8-D-MINI-MPA FESTO Pressure Regulating Valve 1.6MPa

1.6MPa LR-3/8-D-MINI-MPA FESTO Pressure Regulating Valve

Pneumatic connection

Depending on the size, different connection types can be selected:

• Individual ffttings that are fastened via a female thread

• Built-in connections into which the tubing can be directly inserted

Pressuregaugealternatives

The pressure regulator can be ordered with or without a pressure gauge. The interface has a thread of G1/8.

Alternative pressure gauge scale

The scaling of the built-in pressure gauge can be selected. The unit options available are [MPa], [bar] / [psi].

Product Description

FRC / AW / AFR / BFR type air filter regulator and pressure gauge

It includes 2 parts: filter & regulator and lubricator.
But still have 3 function: filtration, decompression and lubricating.
Auto Drain can be selected. All size have overflow function.

Model	MIN			MIDI			MAXI
	OU-1/8"-MINI	OU-1/4"-MINI	OU-3/8"-MINI	OU-3/8"-MIDI	OU-1/2"-MIDI	OU-3/4"-MIDI	OU-3/4"-MAXI	OU-1"-MAXI
	OU-1/8"-MINI	OU-1/4"-MINI	OU-3/8"-MINI	OU-3/8"-MIDI	OU-1/2"-MIDI	OU-3/4"-MIDI	OU-3/4"-MAXI	OU-1"-MAXI
	OU-1/8"-5M-MINI	OU-1/4"-5M-MINI	OU-3/8"-5M-MINI	OU-3/8"-5M-MIDI	OU-1/2"-5M-MIDI	OU-3/4"-5M-MIDI	OU-3/4"-5M-MAXI	OU-1"-5M-MAXI
Working Medium	Filtered compressed Air
Working Medium	Filtered compressed Air
Features of Structure	Sintered filter with water spartpr
Features of Structure	Sintered filter with water spartpr
Mounting Type	pipe,brackets,plate
Assemby position	vertical±5
Connection	G1/8"	G1/4"	G3/8"	G3/8"	G1/2"	G3/4"	G3/4"	G1"
Standard Flow Rate	700	1000	1200	2000	2600	2600	7000	8000
	800	1300	1500	2500	2800	2800	8500	8700
	600	850	1050	1700	1800	2100	6500	7200
Working Pressure	0.5-12 bar
Working Pressure	0.5-12 bar
Working Temperature	0-60
Working Temperature	0-60
Primary Pressure	1-16 bar
Primary Pressure	1-16 bar
Grade of filtration	40um/5um
Max.Capacity	22ml
recommended Oil	ISO VG32 or Equivalent Oil
Filter Precision	40UM,5UM
Min Lubricant Flow Rate	3L/MIN			6L/MIN			10L/MIN

Packing and Shipping:

Packaging and Shipping for Pneumatic Filter Regulator Lubricator:

The filter regulator lubricator is packed in a box and sealed with a protective film to ensure that the product is not damaged during shipping. We also use a special layer of foam to reduce shock and vibration during transportation. We use a high-quality carton to ensure that the product is safe and secure during shipping.
