Product Description:
The ASCO solenoid valve operates by controlling the opening and
closing of the valve through the on/off of a solenoid coil. This
movement controls the mechanical device. The working principle of
ASCO solenoid valves can be classified into three types: pilot
operated, direct acting, and step-by-step direct acting.
When the pilot operated solenoid valve is turned on, the
electromagnetic coil generates a force that opens the pilot hole.
This action causes the pressure in the upper chamber to decrease,
creating a pressure difference that pushes the closing member
upward and opens the valve. If the power is turned off, the
electromagnetic force disappears, the pilot hole closes due to the
action of the spring, and the valve closes.
The direct acting solenoid valve, when powered on, generates a
magnetic force that lifts the closing component and opens the
valve. When power is cut off, the magnetic force disappears, the
closing element is pressed against the valve seat due to the action
of the spring, and the valve closes.
The step-by-step direct acting solenoid valve is a combination of
direct acting and pilot operated principles. It uses
electromagnetic force to open the valve without a pressure
difference or with a small pressure difference. When there is a
pressure difference, it uses pressure to push the valve. If there
is a power outage, it will turn off.
Based on these working principles, ASCO solenoid valves are used in
industrial control systems to manage the direction, flow rate,
speed, and other parameters of the medium. It ensures control
accuracy and flexibility.
| SCG551A001MS | SCG531C002MS | EF551H401MO |
| SCG551A002MS | SCG531C017MS | EF551H402MO |
| EFG551A001MS | SCG531C018MS | SCB320B174 |
| EFG551A002MS | EFG531B017MS | EF8320G174 |
| SCG551A017MS | EF551B401MO | EF8210G003 |
| SCG551A018MS | EF551B402MO | EF8210G089 |
| SCG553A001MS | EF8551B401MO | NF8327B102MO |
| SCG553A002MS | NF8551B401MO | WSNF8327B102MO |
| SCG553A017MS | NF8551B402MO | 8262G138 |
| SCG553A018MS | EF551G401MO | 8551A421 |
| SCG531C001MS | EF551G402MO | VCEFCM8551B401MO |
Applications:
The ASCO Solenoid Valve is suitable for a wide range of
applications, and it is commonly used in industries such as oil and
gas, chemical, and water treatment. It is capable of controlling
the flow of liquids and gases, making it ideal for situations where
precise regulation is required.
The Solenoid Valve can function in a temperature range of -25°C To
+60°C, making it ideal for use in extreme weather conditions. The
Seal materials used in this product include NBR (nitrile) + PUR
(polyurethane), providing excellent resistance to wear and tear.
The Core tube is made of brass, ensuring durability and longevity.
The ASCO Solenoid Valve has a Differential pressure of 2 - 10,4
Bar, and it can handle a Flow of 1/4 = 700 L/min (ANR) 1/2 = 3000
L/min (5/2, 5/3). This Solenoid valve is suitable for a wide range
of applications, including controlling the flow of liquids and
gases in pipelines, tanks, and other industrial equipment.
The Solenoid Valve is available for purchase with a Minimum Order
Quantity of 1 and has a Negotiable price. The Packaging Details
include Carton /As The Clients Require, and the Delivery Time is
1-7Work Days After Payment. Payment options include T/T, Western
Union, and Paypal, and the Supply Ability is 5000PCs per month.
Overall, the ASCO Solenoid Valve is a high-quality product suitable
for various industrial applications. Its durability, temperature
range, and flow capacity make it an ideal choice for controlling
the flow of liquids and gases in pipelines and other equipment.
Packing and Shipping:
Product Packaging:
The ASCO Solenoid Valve product will be securely packaged to ensure
that it reaches its destination in good condition. It will be
packed in a sturdy cardboard box with sufficient padding to prevent
any damage during transit.
Shipping:
The ASCO Solenoid Valve product will be shipped via a reliable
courier service. Shipping fees will depend on the destination and
the weight of the package. Customers will receive a tracking number
to monitor the status of their shipment.
