Product Description:

The floating joint design is a unique feature of our product, which solves the problems of insufficient absorption of eccentricity and parallelism. This helps absorb the eccentricity between the passive body and cylinder. Additionally, this design also absorbs the insufficient accuracy of parallelism. Moreover, it does not require axis alignment, leading to a simplified installation process.
Our product is also highly efficient, and it ensures connection stability under extreme temperatures. It is suitable for working in environments ranging from -5 ℃ to 60 ℃. This high temperature specification guarantees the durability of the product and a long lifespan.
In addition, our product can handle high loads. It has a maximum applied tensile force on both the compression and tension sides of 28000 N, demonstrating remarkable load-bearing capacity.

Our product is available in basic installation type, which provides a stable connection method 2. It is suitable for cylinders with a diameter of 100mm. The standard thread specification is M26X1.5, which allows for easy connection with cylinders and other pneumatic components. Moreover, its swing angle is ± 5 °, which allows for a certain eccentricity of 0.5mm, hence, providing greater flexibility and adaptability.
The pressure range of our product is between 0.05 to 1 MPa, which makes it suitable for various working pressures. For to its efficiency, our product can perform under environmental and fluid temperatures ranging from -5~60 ℃, making it widely adaptable to various working environments.

Technical Parameters:

Applications:

SMC's JA series floating joints are suitable for connecting cylinders and hydraulic cylinders, particularly in situations where eccentricity and parallelism need to be absorbed. Thanks to their excellent design and performance, these floating joints ensure a safe and secure connection solution for pneumatic and hydraulic systems.

Automated machinery requires a stable and secure connection solution when connecting cylinders and driven bodies. SMC's JA series floating joints provide an effective connection solution to ensure the stable operation of the system. With these floating joints, you can be confident your automated machinery is working efficiently and effectively.

Efficient handling is critical, and the connection of cylinders plays an essential role in ensuring the smooth operation of the system. SMC's JA series floating joints provide a stable and reliable connection solution that improves handling efficiency and ensures the stable operation of cylinders in the handling system.

Market Positioning: SMC's JA series floating joints offer an efficient, flexible connection solution for pneumatic systems owing to their exceptional design and performance. This makes them widely used in the industrial automation sector.
User Evaluation: Users highly praise SMC's JA series floating joints for their ability to absorb eccentricity and insufficient parallelism, high temperature tolerance, and high load response ability, which provide users with a stable and reliable pneumatic connection solution.
In summary, SMC's JA series floating joints are an efficient and reliable solution for connecting pneumatic and hydraulic systems with their excellent design and performance. This makes them widely used in the industrial automation sector, and users highly rate them for their durability and reliability.

Packing and Shipping:

Product Packaging:

• The SMC Solenoid Valves will be packed securely in a sturdy cardboard box.
• The product will be wrapped in bubble wrap to prevent any damage during shipping.
• The box will also include a user manual and installation guide.

Shipping:

• The product will be shipped via a reliable courier service within 2-3 business days.
• The shipping cost will be calculated based on the destination and weight of the package.
• Customers will be provided with a tracking number to monitor the delivery status of their order.
