Product Description:
Design Features:
The floating joint design of this product is a major design
feature, as it is able to absorb the eccentricity between the
passive body and the cylinder, as well as the insufficient accuracy
of parallelism. This design feature eliminates the need for axis
alignment, greatly simplifying the installation process.
Additionally, this product is suitable for working environments
ranging from -5℃ to 60℃, ensuring connection stability even in
extreme temperatures. Finally, the maximum applied tensile force on
both the compression and tension sides is 28000 N, which
demonstrates excellent load bearing capacity.
Technical Specifications:
This product is available in a basic installation form, providing a
stable connection method 2. It is designed to be used with
cylinders with a diameter of 100mm and has a thread specification
of M26X1.5, which conforms to standard thread specifications and is
easy to connect with cylinders and other pneumatic components.
The swing angle of this product is ±5° which allows for a certain
eccentricity of 0.5mm. This design feature provides greater
flexibility and adaptability. The pressure range of this product is
0.05-1MPa, making it suitable for various working pressures.
Finally, this product is suitable for use in a variety of working
environments, with both environmental and fluid temperatures
ranging from -5℃ to 60℃.
Technical Parameters:
| Attribute | Value |
|---|
| Cylinder Used | Air Cylinder / Hydraulic Cylinders |
| Connection Type Cylinder Side | Tapped |
| Color | Black |
| Series | JA Series |
| Connection | Flange |
| Type | Fittings |
| Hydraulic cylinder floating joint | SMC floating joint |
| JA6-3-050 | JA80-20-150 |
| JA10-4-070 | JA80-20-250 |
| JA15-5-080 | JA80-22-150 |
| JA15-6-100 | JA100-24-300 |
| JA20-8-100 | JA100-26-150 |
| JA20-8-125 | JA100-27-150 |
| JA20-8-150 | JA100-27-200 |
| JA25-10-150 | JA125-27-200 |
| JA30-10-125 | JA140-30-150 |
| JA32-10-100 | JA160-30-200 |
| JA40-12-125 | JA160-33- 200 |
| JA40-12-150 | JA160-36-150 |
| JA40-12-175 | JA160-36-200 |
| JA40-14-125 | JA180-40-150 |
| JA40-14-150 | JA180-40-200 |
| JA63-16-150 | JA180-42-150 |
| JA63-16-200 | JA180-42-200 |
| JA63-18-150 | |
Applications:
Application Scenarios:
SMC's JA series floating joints are versatile components suitable
for various applications. They are commonly used in pneumatic and
hydraulic systems to connect cylinders and hydraulic cylinders.
They are particularly useful in situations where eccentricity and
parallelism need to be absorbed. They are also commonly used in
automated machinery to connect cylinders and driven bodies,
ensuring stable system operation, and in handling systems to
improve efficiency by ensuring stable cylinder operation.
Market Positioning and User Evaluation:
SMC's JA series floating joints are designed to provide efficient
and flexible connection solutions for pneumatic systems. With their
excellent design and performance, they are widely used in the field
of industrial automation, positioning themselves as a reliable
solution provider. The JA series floating joints have been well
received by users who give high praise for their ability to absorb
eccentricity and insufficient parallelism, high-temperature
tolerance, and high load response ability. SMC's JA series floating
joints are a dependable solution that provides a stable and
reliable pneumatic connection solution.
Conclusion:
In conclusion, SMC's JA series floating joints provide an efficient
and reliable solution for connecting pneumatic and hydraulic
systems. They are versatile, with excellent design and performance,
and have a wide range of applications in the field of industrial
automation. With their ability to absorb eccentricity and
insufficient parallelism, high-temperature tolerance, and high load
response ability, the JA series floating joints are proven to be a
dependable solution, providing users with a stable and reliable
pneumatic connection solution.
