Product Description:
When it comes to design features, this particular floating joint
provides a solution to the insufficient absorption of eccentricity
and parallelism. It is specially engineered to absorb the
eccentricity between the passive body and cylinder, as well as any
insufficient parallelism, without the need for axis alignment. This
simplifies the installation process, saving time and effort.
Furthermore, this floating joint features a high-temperature
specification, making it suitable for use within environments
ranging from -5 ℃ to 60 ℃. This ensures that the connection remains
stable even when subjected to extreme temperatures.
Another noteworthy design feature is the high load handling
capacity. The maximum applied tensile force on both the compression
and tension sides is 28,000 N, demonstrating excellent load-bearing
capacity.
As for the technical specifications, the installation form is a
basic type that provides a stable connection method 2. It is
designed to suit cylinder 1 with a diameter of 100mm, and the
thread specification used is M26X1.5, a standard thread
specification that makes it easy to connect with cylinders and
other pneumatic components.
The swing angle is ± 5 °, allowing for a certain eccentricity of up
to 0.5mm, providing greater flexibility and adaptability. This
floating joint is also suitable for various working pressures, with
a pressure range of 0.05-1 MPa. Additionally, it is designed to be
used within various working environments, with both environmental
and fluid temperature ranging between -5~60 ℃.
Technical Parameters:
| Attribute | Value |
|---|
| Type | Fittings |
| Color | Black |
| Connection Type Cylinder Side | Tapped |
| Series | JA Series |
| Cylinder Used | Air Cylinder / Hydraulic Cylinders |
| Connection | Flange |
SMC JA Series Floating Joints, Cylinder exhaust tailpipe joint, SMC
floating joint
Applications:
Pneumatic and hydraulic systems can benefit from utilizing SMC's JA
series floating joints. These joints are particularly suitable for
connecting cylinders and hydraulic cylinders, especially in
situations where eccentricity and parallelism need to be absorbed.
The floating joints ensure a stable and flexible connection,
improving the overall performance of the system.
Automated machinery requires precision and stability to ensure
efficient operation. The JA series floating joints are commonly
used in connecting cylinders and driven bodies, ensuring that the
system operates smoothly and reliably. By utilizing the floating
joints, automated machinery can achieve higher levels of
productivity while reducing the risk of downtime due to faults or
malfunctions.
In handling systems, the JA series floating joints ensure a stable
operation of cylinders, which in turn improves handling efficiency.
Whether in manufacturing plants or logistics centers, quick and
efficient handling systems are essential in maintaining the smooth
flow of materials and goods. By using SMC's floating joints, the
handling system can operate with greater consistency and
reliability.
SMC's JA series floating joints are well-positioned in the market,
providing an efficient and flexible connection solution for
pneumatic systems. Their excellent design and performance make them
a popular choice in the field of industrial automation. The JA
series floating joints are widely used in connecting cylinders and
hydraulic cylinders, and other components of pneumatic systems.
Users have highly praised the performance of SMC's JA series
floating joint. The floating joints can absorb eccentricity and
insufficient parallelism, tolerate high temperatures, and respond
to heavy loads. Users have experienced the benefits of a stable and
reliable pneumatic connection solution, which enables them to
operate their systems with greater confidence and efficiency.
In summary, SMC's JA series floating joints provide an efficient
and reliable solution for connecting pneumatic and hydraulic
systems. With their excellent design and performance, they are
widely used in the field of industrial automation. The JA series
floating joints ensure that cylinders and other components operate
with greater consistency and reliability, improving overall system
performance.
