Product Description:
The CY1S magnetic coupling rodless cylinder is designed to operate
within a specific pressure range, ensuring reliable performance in
various industrial applications. It has a maximum working pressure
of 0.7 MPa and a minimum pressure of 0.18 MPa.
Temperature adaptability is another significant feature of the CY1S
magnetic coupling rodless cylinder. The product is designed to
operate in an environment and fluid temperature range of -10 to
60°C, making it suitable for use in various environments, including
extreme temperature environments.
The speed of the piston is another important property of the CY1S
magnetic coupling rodless cylinder. The cylinder's piston speed
ranges from 50 to 400 millimeters per second, which provides fast
and smooth motion and makes it ideal for applications that require
high-speed operation.
The installation space required by the cylinder is minimal, thanks
to its unique design. The action of the rodless cylinder piston is
transmitted to the external slider through magnetic coupling force,
without the need for a piston rod. Hence, the installation space is
less than that of a regular cylinder.
The sealing performance of the CY1S magnetic coupling rodless
cylinder is excellent. The piston is separated from the slide table
to prevent dust and dirt from entering the system. This separation
extends the service life of the rodless cylinder.
Another notable feature of the cylinder is the buffer device. The
CY1S magnetic coupling rodless cylinder comes equipped with fixed
buffer devices at both ends, ensuring smooth and impact-free
reversing action while avoiding mechanical damage.
The CY1S magnetically coupled rodless cylinder boasts a theoretical
force of 500N, a maximum load capacity of 2000N, and a maximum
force distance of 10Nm, making it suitable for various industrial
applications. Especially in scenarios that require high-speed,
smooth motion and work in extreme temperature environments.
Technical Parameters:
| Piston speed | 50-500mm/s |
| Temperature range | -10—60℃ |
| PROOF PRESSURE | 1.05MPA |
| Brand | SMC |
| Fluid | Air |
| Custom-made Specifications | 0.18 To 0.7 |
This product is the CY1S magnetic coupling rodless cylinder and is
customizable to meet your needs. It is a type of magnetic coupling
rodless cylinder.
Applications:
The CY1S series of SMC rodless cylinders is suitable for a wide
range of applications. These cylinders are designed to work with
air as the fluid, and have a proof pressure of 1.05MPA. The
custom-made specifications for these cylinders range from 0.18 to
0.7. The temperature range for these cylinders is from -10℃ to 60℃,
making them suitable for use in a variety of environments.
The CY1S series of magnetic coupling rodless cylinders is ideal for
use in industrial applications. These cylinders are widely used in
the automation industry, for applications such as material
handling, packaging, and assembly. They are also used in the
automotive industry, for applications such as welding and painting.
The CY1S series of SMC rodless cylinders is also suitable for use
in the food and beverage industry, where hygiene is of utmost
importance. These cylinders are designed to be easy to clean, with
smooth surfaces and no crevices where dirt can accumulate. They are
also suitable for use in the pharmaceutical industry, where clean
and sterile environments are necessary.
In conclusion, the CY1S series of SMC rodless cylinders is a
high-quality product that is suitable for a wide range of
applications. With its excellent performance, high quality, and
custom-made specifications, these cylinders are an ideal choice for
those looking for a reliable and efficient product.
